The Alfa Laval IM-20 Rotary Jet Mixer effectively handles liquid mixing, gas dispersion, powder mixing, and tank cleaning while reducing mixing time, energy consumption and costs.
Patented, and based on proven Rotary Jet Head technology, the IM-20 provides quick, efficient and uniform mixing without any batch rotation or use of baffles. It also ensures greater process flexibility, making it easy to switch to product formulations with diverse viscosities, densities and volumes
The IM-20 Rotary Jet Mixer is designed for liquid mixing, gas dispersion (aeration and carbonation), deaeration, and powder mixing in process and storage vessels from from 5 to 200 m3 in size across the dairy, food, beverage, brewery, healthcare, home and personal care, and biotechnology industries.
The IM-20 also acts as a superb Cleaning-in-Place (CIP) system in an empty tank, saving water, cleaning fluids and energy compared to spray ball CIP systems.
Lubricant: Self-lubricating with the mixing/cleaning fluid
Connection: Standard thread 2* BSP or NPT, female
Min, tank opening: See dimension drawings
Working Pressure: 2 – 12 bar
Recommended pressure during mixing: 2 – 6 bar
Recommended pressure during CIP: 5 – 6.5 bar
Max. working temperature: 95°C
Max. ambient temperature: 140°C
ISO-MIX Rotary Jet Mixers helped Royal Unibrew improve yeast pitching consistency
Alfa Laval’s Rotary Jet Mixer technology helped Pharma Nord extend the shelflife of their dietary supplements.
Extend the performance of your Mixer
Boost hygiene while reducing energy and water use. Alfa Laval’s range of processing solutions can help you improve yield and drive greater efficiency.
Alfa Laval provide high-performance components to maximise efficiency in applications across the dairy industry, from yoghurts and cheeses to milk, cream and butter.
inTank has a long history of supplying process equipment to both small local producers and global breweries. Alfa Laval’s solutions bring out the best in your beer and brewery.
