The Alfa Laval IM-15 Rotary Jet Mixer effectively handles liquid mixing, gas dispersion, powder mixing, and tank cleaning while reducing mixing time, energy consumption and costs.
Patented, and based on proven Rotary Jet Head technology, it provides quick, efficient and uniform mixing without any batch rotation or the use of baffles. It also ensures greater process flexibility, making it easy to switch to new product formulations with diverse viscosities, densities and volumes.
The IM-15 Rotary Jet Mixer is designed for liquid mixing, gas dispersion (aeration and carbonation), deaeration, and powder mixing in process and storage vessels from from 2 to 100 m3 in size across the dairy, food, beverage, brewery, healthcare, home and personal care, and biotechnology industries. The IM-15 also acts as a superb Cleaning-in-Place (CIP) system in an empty tank, saving water, cleaning fluids and energy compared to spray ball CIP systems.
The Alfa Laval IM-15 Rotary Jet Mixer consists of a Mixer body, turbine and nozzles. Shaft, seal and gearbox are unnecessary, unlike traditional systems using propeller mixers, and this creates a more hygienic mixing solution. Excellent mixing can be achieved without the use of baffles or any batch rotation. The complete system is built with a circulation loop, enabling liquid to be pumped from the bottom of the tank and back into the Rotary Jet Mixer
Lubricant: Self-lubricating with the mixing/cleaning fluid
Connection: Standard thread 1.5* BSP or NPT, female
Min, tank opening: See dimension drawings
Working Pressure: 2 – 12 bar
Recommended pressure during mixing: 2 – 6 bar
Recommended pressure during CIP: 5 – 6.5 bar
Max. working temperature: 95°C
Max. ambient temperature: 140°C
ISO-MIX Rotary Jet Mixers saved this British food producer over £10,000 per tank.
Alfa Laval’s multifunctional Rotary Jet Mixer system makes it possible to deoxygenate, carbonate, mix powders, such as caffeine and taurine, and blend aroma, sugar syrup and water all in the same loop.
Extend the performance of your Mixer
The IM-15 Rotary Jet Mixer can be utilised for a wide range of tank mixing and cleaning duties across the Dairy, Food, Beverage, Personal Care, Biotechnology and Pharmaceutical industries.
Our range of solutions are centred around increasing output while minimising contamination and enhancing efficiency, making them ideal for applications in the personal care industry.
