Application
The Alfa Laval MultiJet 25 Rotary Jet Head delivers 3D indexed impact cleaning over a defined period. It is ideal for duties where cost-effective impact cleaning with Rotary Jet Heads is desired, but compliance with hygienic design standards is not necessary. The device is suitable for process, storage, and transportation tanks between 15 and 150 m3 (4,000 to 40,000 US gallons). It is designed to work under conditions where finer particles in the cleaning media may be re-circulated through the machine.
Working Principle
The discharge of the cleaning fluid drives the nozzles in a geared rotation around the vertical and horizontal axes. In the first cycle, the nozzles draw out a coarse pattern on the tank surface. The subsequent cycles gradually increase pattern density, until a full pattern is developed after 8 cycles.
Material Certificate, 2.1 (standard)
ATEX (optional)
The choice of nozzle diameters can optimise jet impact length and flow rate at the desired pressure. A 2.1 material certificate and an ATEX certification are available.
Self-lubricates with cleaning fluid
Max. throw length: 9 – 14 m
Impact throw length: 4 – 8 m
Working pressure: 3 – 8 bar
Recommended pressure: 5 – 6.5 bar
The flow of the cleaning fluid makes the nozzles perform a geared rotation around the vertical and horizontal axes. In the first cycle, the nozzles lay out a coarse pattern on the tank surface. The subsequent cycles gradually make the pattern denser until a comprehensive cleaning pattern is achieved, after which the machine will start over and perform the next full cleaning pattern.
