SaniMidget SB UltraPure
Rotary Spray Head
Alfa Laval SaniMidget SB UltraPure Rotary Spray Head
Application
The Alfa Laval SaniMidget SB UltraPure Rotary Spray Head is purpose-designed to be self-cleaning, self-draining and fully inspectable. Its novel, patent-pending one-clip assembly makes installation, disassembly and inspection easy, without compromising cleanability or drainability. The SaniMidget SB UltraPure efficiently replaces the traditional Static Spray Ball, as it can impact any part of the vessel wall that lies within the 270° upward pattern – at a lower flow rate, with an equally low pressure.
Working principle
The flow of cleaning media creates rotation in the head of the SaniMidget SB UltraPure, laying out fans of water in a swirling pattern on the entire area contacted by the spray pattern. This creates an oscillating impact in the 270° upward pattern and a dynamic cascading jet that coats all interior surfaces of the tank, vessel or reactor. The SaniMidget SB UltraPure is designed according to EHEDG and GMP guidelines and meets the requirements of 3-A standards.
SaniMidget SB Ultrapure Spray Pattern
360º
270º Up
SaniMidget SB
Ultrapure Certificates
Certificate of Conformity (standard)
3.1, Q-doc incl. FAT/SAT, 3A and ATEX (optional)
SaniMidget SB UltraPure vs Static Ball
Benefits
- Fully maintainable
- 40% Faster cleaning increases uptime for production
- Up to 40% reduction in CIP use and effluent to drain
- Self-cleaning and Self-draining
- 40% Reduction in CIP cleaning cycle times
- Dynamic 360° full wetting cleaning coverage
- Simple to retrofit, no change to pump or pipework
SaniMidget SB UltraPure Key Features
Cost-Effective Cleaning
Rotary Spray Heads like the SaniMidget SB UltraPure effectively clean tanks using less water, less energy and less cleaning agents than Static Spray Balls. This helps reduce consumption of high-purity water and chemicals.
Efficient Residue Removal
Economic & Sustainable
Performance Reliability
Designed with minimal internal pressure loss, Alfa Laval Rotary Spray Heads rotate at pressures of less than 0.1 bar; however, the recommended operating pressure for the SaniMidget SB UltraPure is 2 bar.
Low Maintenance, Minimal Downtime
Generally speaking, routine inspection is the only maintenance required for Alfa Laval Rotary Spray Head devices. These devices are so reliable that a single device in many cases can meet the requirements of a plant over its entire lifetime. The SaniMidget SB UltraPure is lubricated by the cleaning media it dispenses.
High Product Integrity
Technical Data
Lubricant: Self-lubricates with rinse/cleaning fluid
Wetting radius: Max. 3m
Impact cleaning radius: Max. effective 1.4m
Temperature
Max. working temperature: 95 °C
Max. ambient temperature: 150 °C
SaniMidget SB UltraPure Technical Data
How the SaniMidget SB UltraPure Rotary Spray Head Works
SaniMidget SB UltraPure Rotary Spray
Head Product Documents
Recent Success Story
The Big Cheese in creamery tank cleaning
The Alfa Laval SaniMega Rotary Spray Head cut both CIP time and water usage by over 30% for this Welsh creamery – taking their cleaning time from 43 minutes to 28 minutes per silo.
